Phase Current:5 A
Voltage Range (Line Voltage):90-300VDC, 70-265VAC
Enclosure Rating:20-X
Frequency Range:48-62Hz
Overvoltage Category:II
Insulation Voltage:300V
Pollution Degree:2
Analog Current Inputs Accuracy:±1% of full scale
RTD Inputs Isolation:36 Vpk (isolated with analog inputs and outputs)
Maximum Altitude:2000 m
Tachometer Duty Cycle:> 10%
Trip Coil Supervision:Trickle Current 2 to 5 mA
Underfrequency Pickup Accuracy:±0.02 Hz
Shipping Weight:7.7 kg or 17 lbs
Digital Inputs:489 Sensor Supply 24 V DC at 20 mA max
Impedance Time Delay:0.1 to 100.0 s in steps of 0.1
Negative Sequence Overcurrent Pickup Level:3 to 100% FLA in steps of 1
Sequential Trip Configurable:Assignable to Digital Inputs 1 to 7
Case Drawout:Fully drawout (automatic CT shorts)
The GE Multilin 489-P5-HI-A20-E is a highly reliable motor management relay designed for generator protection and management. It integrates advanced features to ensure optimal performance and safety in industrial environments.
This relay is equipped with trip and alarm protection, making it an essential component for monitoring and controlling generators. It also includes breaker failure detection and flash memory trip coil supervision, enhancing its reliability and ease of use.
With a wide operating temperature range from -40 to 60°C, this relay can withstand harsh environmental conditions, ensuring consistent performance in various industrial settings. Its robust design and high accuracy make it suitable for demanding applications.
The 489-P5-HI-A20-E features a fully drawout case with automatic CT shorts, providing added safety and convenience during installation and maintenance. It also includes digital inputs and configurable sequential trips, offering flexibility in configuration and operation.
The inclusion of the Enervista 489PC Software allows users to interact and program the relay from a PC, simplifying setup and configuration processes. Additionally, a SR489-CASE draw-out case is included with new factory package versions, ensuring convenient handling and storage.
